Steel Embed Plates
Design your plate dimensions and stud layout. Live 3D preview.
Reviewed before fabrication. Built to your specs.
Preview
3D preview
Enter plate dimensions to generate a preview.
Design Your Embed Plate
Create a custom steel embed plate in minutes—no drawings required.
Plate Dimensions
How It Works
1) Plate
Enter plate length, width, thickness, and material.
2) Studs
Choose a stud layout and set edge dimensions like your drawings.
3) Finish & Quantity
Choose finish, set quantity, and review pricing.
4) Project Info
Add optional job details to help us process faster.
What We Need From You
Plate Dimensions
Use inches. Plate dimensions drive pricing, lead time, and the 3D preview.
Stud Coordinates
Coordinates are measured from the plate center: (0, 0). Positive X is right, positive Y is up. Use the visual editor to avoid layout mistakes.
Frequently Asked Questions
Can you handle custom stud layouts?
Yes. Use the visual editor to place studs, then adjust coordinates precisely in the list.
What does “review required” mean?
Some configurations fall outside our instant-quote rules (e.g., high stud count or non-standard options). We may confirm details before fabrication and final pricing.
Is the 3D preview exact?
It’s representative for visualization. Final layout is per approved drawings and order details.
Can I export documentation?
Yes. You can export a quote PDF, and we can generate shop packet documents after checkout.
